PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine

WANROOETECH is China professional PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine manufacturer,we supplied PDisc Plastic Pulverizer Machine, grinding disc pulverizer, disc mill pulverizer, pulverizing systems, Plastic powder grinder machine,Find Complete Details and price about PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine, please contact us!

Share this:
  • Product Description
  • Parameter
  • Video
  • Optional Components
  • Service


The disc grinding pulverizer machine of the PNMF series are available with disc diameter from 300 to 800 mm. These plastic pulverizer machines are high speed, precision grinders for the processing of medium-hard, impact resistant and friable materials. The material to be pulverized is introduced through the center of a vertically fixed grinding disc which is mounted concentrically with an identical high speed rotating disc. Centrifugal force carries the material through the grinding area and the resulting powder is collected with a blower and cyclone system. Depending on the application, the machines can be equipped with one piece of grinding discs or grinding segments.

The plastic pulverizer machine is mainly composed of the electric motor, disc type blade, feeding fan, vibrating sieve, dust removing system, etc.

According to the customer's needs, you can choose some accessories, such as a converter, vacuum loader, screw loader, magnetic net, metal separator, chiller, pulse dust collector, metering and weighing packaging machine, etc.

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine blade:

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine blade

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine components:

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine components

Technical Features:

1. The new disc design is with high quality, strong resistance and the life of this grinding disc is double the ordinary ones.

2. The newly designed professional bearings are with a high rotation rate. At the same time using only one drive motor, to ensure the efficient grinding crash, which greatly saves the time of machine operation and engineering control.

3. Easy installation and maintenance, just open the door to clean up.

4. The whole milling process is sealed, without dust leakage.

5. Full automatic design, automatically feeding, discharging and sorting.

6. Grinding gap adjustment is simple, just use the feeler gauge and adjust bolts can be fine-tuning.

7. The mill uses the water and wind double cooling system,  Prevent bearing and other parts from overheating.

8. Well-known brand accessories, such as SKF bearings and Siemens motors, can work for a long time, saving the trouble of changing accessories frequently.

9. With a wide range of optional accessories, professional solutions can be developed based on the customer's budget and processing requirements.

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine

Application Areas:

The PNMF series automatic plastic mill is a disk-type plastic pulverizer, which has the advantages of high capacity and low-power, This machine can be used for powder processing of PE, HDPE, PP, PS, ABS, EVA, PET, nylon and other materials.

PNMF series plastic shredders can process powder sizes up to 20-120 mesh.

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine

ModePNMF 300 PNMF 400 PNMF 500 PNMF 600 PNMF 800
Disc Diameter(mm) 300 400 500 600 800
Main motor(kw) 11-15 22-30 37-45 45-55 75-90
Vibrating motor(kw) 0.75 0.75 0.75 1.1 1.5
Capacity(kg/h) 30-50 50-120 100-300 200-400 400-800
Cooling method Air cooling and water cooling
End power size 15-120mesh

*The capacity depends on raw material and end powder size. The machine can be made by clients' requirements.

Optional Components

Magnetic Filter Frame

Metal Separator For Pulverizer Mill

Plastic Granules Feeder


PNWC Air-cooled Type Water Chiller

Automatic Weighing Packing Machine

Delivery Times

30-90 working days since receiving the advance payment. If you cannot wait for this suggested delivery time, please contact us freely, we will make any arrangements we can to meet your requirements.


Wood Pallet, fumigation-free wooden cases if necessary. All the key parts of the equipment will be painted with anti-rust oil before shipment and packing.

PE、LLDPE、LDPE、MDPE、HDPE Disc Plastic Pulverizer Machine packing

Technical documents

WANROOETECH will offer you all necessary documents, e.g. general layout plan, electrical diagram, and user manual after the contract are executed.

Arrangement for inspection, installation and testing work

After informed machines ready for inspection, customer can send engineers to WANROOETECH; Customer also can consign WANROOETECH to finish inspection work.

When the machines are delivered to the customer's factory, please arrange preparation work before engineers arrive if require.

WANROOETECH will send technicians to the factory after preparation work is completed;

Technicians will be responsible for guide on-site installation and testing machines involved.

Meanwhile, technicians will give free training lessons to labors in the customer's factory.

The customer just needs to bear expenses generated for this work, e.g. airplane tickets (round-way), residency, meals, and allowance of USD50 per day for each technician.

Quantity and quality guarantee

A: Quantity/Quality Discrepancy to destination port during transportation:

In case of quality/quantity discrepancy to destination port in transportation, customers should file a claim within 30 days after the arrival of the goods at the port of destination.

B: Guarantee period and after-sales services:

12 month since installation finish and machine normal working. During this guarantee period, WANROOETECH will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, WANROOETECH will provide spare parts at cost.

C: Long-term service:

WANROOETECH will charge the buyer cost of spare parts beyond guarantee time and provide a long-term technical guide.
