Master Batch Dose Feeder

PNDF series volumetric masterbatch dosers are adaptable to auto-proportion mixing of new materials, regrinds, masterbatch or additives, adaptable to injection, extrusion or blow molding field. A stepper motor is used in this series, according to the set mixing proportion, the microprocessor accurately controls rotation of the high precise dosing screw to squeeze out materials with an deviation of ± 1%. The mixing precision of each batch can be controlled ± 1%. Each time the machine starts running, it will automatically check the scale to ensure the best quality. This doser can connect with various molding machine signals in synchronicity, to ensure the stability of the products.

Quantity:

Share this:

Inquire

Product Description
Parameter

General Introduction:

Features Specifications:

1. Unit is comprised of standard modules for ease of cleaning, disassembly and interchangeability;

2. Using the high accuracy hybrid stepping motor, measurement accuracy and output scope;

3. Motor drive directly, without gearbox, long service life. Maintenance-free.

4. The adopted PLC panel shows reliable performance and easy maintenance.

5. Can store 50 sets of formula,can quickly start the machine.

6. Dosing screws are chrome plated for durability.

7. The roof-shaped quick-change ( the dosing section can be removed without granulate leaking from the neckpiece), large opening on the side of the neckpiece, large window and improved static blending.

Master-batch-Dose-Feeder-2

Technical Parameters：

Model	Single color unit			Double color unit	Three color unit
Model	PNDF-12	PNDF-14	PNDF-16	PNDF-D2	PNDF-D3
Motor Power (kw)	0.3	0.3	0.3	0.3*2	0.3*3
Rotary Speed (r.p.m)	1.8-300	1.8-300	1.8-300	1.8-300	1.8-300
Mixer power (kw)	0.09	0.09	0.09	0.09	0.09
Screw Dia. (mm)	12	14	13	**	**
Output Capacity (kg/hr)	0.05-20	0.1-40	0.5-64	*	*
Storage Capacity(L)	13	13	13	13	13
Main Material Hopper (L)	Optional	Optional	Optional	Optional	Optional
Mixer	Optional	Optional	Optional	Optional	Optional
Floor Stands	Optional	Optional	Optional	Optional	Optional
Dimensions
H(mm)	450	450	450	450	520
W(mm)	560	560	560	980	1050
D(mm)	310	310	310	310	1050
kg Approx.Net Weight	25	25	25	45	75

Note:

1) ”*” means the output capacity depends on the screw selected, data of the single color doser can be a reference. For example PNDF-12, output capacity is 0.06-20kg/h.

2) “**” stands for external diameter of screw is up to model selected.

3) The output proportion of all models are 1.2, diameter 2-3mm masterbatch in a test criteria continuous running,
