Fully Automatic Hydraulic Metal Baler Aluminium Can Double Head Baler Machine

Fully Automatic Hydraulic Metal Baler Aluminium Can Double Head Baler Machine

Metal baler is mainly used in steel mills, recycling and processing industries, and non-ferrous and ferrous metal smelting industries. The hydraulic baler can extrude various metal scraps (steel shavings, scrap aluminum cans, scrap steel, scrap aluminum, scrap copper, scrap stainless steel, and scrapped automobile scrap, etc.) into spheroid, octagon, cylinder and other qualified furnace materials , Can reduce the cost of transportation and smelting, but also can increase the furnace speed.

Quantity:

Share this:

Tags: Aluminum can baler

Inquire Download PDF

Product Description
Parameter
Video

Usage:

Metal strapping machines play an important role in steel mills, recycling and processing industries, as well as non-ferrous and black metal smelting industries. It utilizes hydraulic technology to effectively extrude various metal scraps, such as steel shavings, scrap aluminum cans, scrap steel, scrap aluminum, scrap copper, scrap stainless steel, and scrapped automotive waste, into qualified furnace materials that meet smelting requirements, such as spherical, octagonal, cylindrical, etc. This processing method not only greatly reduces transportation and smelting costs, but also significantly increases furnace speed by improving the density and uniformity of furnace materials, thereby improving overall production efficiency and economic benefits.

Baler Machine, Metal Baler, Aluminium Cans Baler, Hydraulic Baler, Double Head Baler Machine

Features:

Automatic chain bale ejector for quickly and easily ejecting the bales out form the machine

The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation

Equipped with Euro and U.S. standard anti-rebound gate structure which makes sure the safety of operation

Special ram guides design makes the platen not slope because of uneven materials feeding during compression

Equipped with NOK seals that from Japan means longer lifespan of the seals

Equipped with A.M.C oil pipe joints that from Japan ensures the machine far away from oil leakage problems

Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which replacing the common coupling connection so that extend the lifespan of the pump

Model	PNDB-300KL8060	PNDB-400KL10060	PNDB-500KL11070	PNDB-800KL12080
Pressure	30tons	40 tons	50tons	80tons
Feeding Opening Size (L*H)	800*500mm	1000*500mm	1100*500mm	1200*500mm
Baling chamber Height	1500mm	1500mm	1500mm	1700mm
Bale Size (LWH, H is adjustable)	800600(200-1000)mm	1000600(300-1000)mm	1100700 (300-1000)mm	1200800(300-1200)mm
Bale Weight	30-120kgs	60-180kgs	90-270kgs	200-380kgs
Power	5.5kw	7.5kw	11kw	15kw
Weight	1400kgs	1700kgs	1900kgs	2500kgs
Overall Dimensions	12808503300mm	148010003400mm	160011003500mm	170012003900mm
