Four Shaft Shredder

Four shaft shredder is a heavy-duty machine. They have advantages in standardization and modularization design, high interchangeability for their components. Their blades are made of special alloy steel with high strength, strong anti-wear, and reparability. The drive part takes advantage of 4 motors, heavy planet gearboxes to make main shafts rotate at different speeds. The electric part takes advantage of the PLC program and touch screen control with the video monitor system and the automatic detecting overload protection function. They have low rotation speed, big torque, and low noise characters. So they have won customers’ trust and got popularity in the shredding process in the recycling industry They fit for shredding large and hard objects such as car body, solid industrial waste, medical waste, e-waste, PE pail, PE frame, PE bottle, metal can, metal pail, intertexture bag, fridge, electric circuit board, paper box, wood and so on.

Quantity:

Share this:

Tags: Plastic Shredder Plastic Shredder Four Shaft Shredder

Inquire Download PDF

Product Description
Parameters
Video

Four Shaft Shredder Description：

Four Shaft Shredder blades:

Four Shaft Shredder blades

Four Shaft Shredder Features:

High quality blade: Made of D2 steel, wear-resistant and durable.

Top electronic components: Siemens and Schneider combination to ensure stable operation.

Intelligent control: Combining microcomputer technology with speed changes and operational functions to improve efficiency.

Automatic protection: The reverse sensor prevents overload and jamming, protecting the machine.

Convenient maintenance: The split type bearing seat design allows for quick replacement of blades.

Low noise and high efficiency: Running at low speed and high torque, maximizing power and reducing noise.

Four Shaft Shredder Applications:

Four Shaft Shredder Applications

(1) Bucket products: PE bucket, metal drum, paint bucket, intermediate -bulk container (IBC) and dustbin

(2) Wastes: household waste, medical waste, kitchen waste, industrial waste, park waste

(3) Plastic products: PE bottle, PE frame, PE block, PE can

(4) Metal products: aluminum profile, oil filter, car shell, pop-top can, metal can

(5) Paper: newspaper, card paper, corrugated paper, copy paper

(6) Electronic appliances: refrigerator, circuit board, laptop shell, TV set shell, CD disk

(7) Glass

four shaft shredder application

Model	PNFS130100	PNFS130120	PNFS130140	PNFS130180	PNFS160140	PNFS160160	PNFS160200
Motor power	2×15+2×30	2×15+2×30	2×15+2×37	2×15+2×37	2×30+2×45	2×30+2×45	2×30+2×55
Main blade thickness （mm）	50	50	50	50	50	50	50
Main blade tactical diameter （mm）	430	430	430	430	534	534	534
Number of main blades （pcs）	20	24	28	36	28	32	36
Main shaft rev（rpm）	10-15	10-15	10-15	10-15	10-15	10-15	10-15
Screen diameter （mm）	60	60	60	60	60	60	60
Cutting chamber （mm）	1300×1000	1300×1200	1300×1400	1300×1800	1600×1400	1600×1600	1600×2000
Dimension (LxWxH）（mm）	3550×2000 x3100	3650×2000 x3100	3850×2000 x3100	4250×2000 x3100	4160×2200 x3630	4360×2200 x3630	4560×2200 x3630
Weight （kg）	11500	12500	13500	15500	17000	18000	19000
