PVC Cable Compounding Pelletizing Granulating Machine PVC Cable Compounding Pelletizing Granulating Machine

PVC cable materials Compounding & Pelletizing Line is double stage pelletizing machine. The first stage uses high speed co-rotating parallel twin screw extruder and the second stage is single screw extruder. This combination is because of the characteristics of high speed, strong compounding twin screw and low speed, low temperature, low shear single screw. This line enhances advantage and avoids disadvantage, which is the preferred choice for heat and shear sensitivity of materials compounding modification. It is suitable for granulation of PVC cable material,s hoe sole material, transparent bottle material, PE/EVA carbon black masterbatch and other crosslinked cable materials. This equipment has admirable compounding effect and easy temperature control. It is of excellent safety and simple operation.

Quantity:
Share this:
  • Product Description
  • Parameters
  • Video

Description:
PVC cable materials Compounding & Pelletizing Line is double stage pelletizing machine. The first stage uses high speed co-rotating parallel twin screw extruder and the second stage is single screw extruder. This combination is because of the characteristics of high speed, strong compounding twin screw and low speed, low temperature, low shear single screw. This line enhances the advantage and avoids disadvantage, which is the preferred choice for heat and shear sensitivity of materials compounding modification. It is suitable for granulation of PVC cable material,shoe sole material, transparent bottle material, PE/EVA carbon black masterbatch and other crosslinked cable materials. This equipment has an admirable compounding effect and easy temperature control. It is of excellent safety and simple operation.


Features:
The screw is made of high tool steel 38 CrMoALA or W6Mo5Cr4V2. Special screw combination Euro-style rectangle barrel, reflux refrigeration channel optimized and disposed of, which makes temperature difference in D areas smaller.
Innovated design of the heater-tightened style ensures high efficiency of heat transfer and high longevity of the heater.
The material is used high quality nitride steel, corrosion-proof, or antifriction with corresponding processed specially designed two sets of vacuum.
A new-style project of parallel three-axis driving makes the convex axis, convey Chain, decelerate and torque get together, which keep it compact, and the key bearings are imported soakage and spraying lubrication integrate smoothly technics, strengthening of tooth face, so they can ensure high torque, high precision and low noise.
The selected material of drive components is dainty, including super intention alloy, cementite steel, cementing and grinding.


Working Flow:
Screw feeder → Efficient extruder → Non-stop hydraulic screen filter changer →  Cutting → Blower → Storage hopper → Electric control panel
1. Screw feeder: the first step of the pelletizing recycling machine, Pvc plastic flakes/scraps conveyed into the hopper through screw, the screw connects the sensor to detect the material in the hopper, once the flakes are full in the hopper, the screw will stop, and once empty, the screw feeder will begin working.
2. Extruder: to plasticization and degassing, a specialized single screw extruder applied to melt the pre-compacted material. The plastic scraps will well be melted, plasticized in the first stage extruder, and the plastic will be extruded by the second stage extruder. With double-zone vacuum degassing system, volatiles such as low molecular and moisture will be removed efficiently, especially suitable to heavy printed film and material with some water content.
3. Non-stop hydraulic screen filter changer: double stage filtering, fore filtering in the first extruder, and fine filtering in the second extruder, to reduce the frequency of filtering sieves changing. The requirements on the filter technology depend heavily on the quality of the input material as well as the planned use of granules.
4. Cutting pelletizing: supplied with speed steel and hard alloy steel cutting blades for reliable performance. A compact structure allows less maintenance.


Advantage:
Very low labor request.
Automatic constant temperature control.
CE certification, ISO9001 certification, SGS certification
Stable running, higher output and lower energy consumption.
Configuration based on client requirement and material, and give reasonable suggestions.


Application :
This PVC plastic pelletizing machine is designed specializes for recycling the recycled washed plastic PVC plastic flakes/scraps, such as PVC pipe flakes/scraps, PVC sheet flakes/scraps, etc.

PVC Cable Pelletizing Machine,PVC Granulating Machine,PVC Compounding Pelletizing ,Plastic Granulating Machine,Plastic Pelletizing Machine

ModelScrew Diameter(mm)L/DRotate Speed(rpm)Main Motor(kw)Capacity(kg/h)
SJPT2021.732-4060042-10
SJPT353528-4840018.55-30
SJPT5050.528-40400/60011/1540-80
SJPT6562.428-48500/60055/75100-300
SJPT7271.228-48400/50090/110300-600
SJPT9291.728-40400/500220/250600-100



×
