Soft Plastic Baler Plastic Film Fiber Baling Press Machine
Soft Plastic Baler Plastic Film Fiber Baling Press Machine

Soft Plastic Baler Plastic Film Fiber Baling Press Machine Soft Plastic Baler Plastic Film Fiber Baling Press Machine

Usage:
Widely used for compressing soft plastics like PE/PP Films
Features:
Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine
Wide feed opening door lifts upwards automatically when the platen goes up

Quantity:
Share this:
  • Product Description
  • Parameter

Usage:

Specially used for compressing all kinds of nature fiber like palm fiber, coir fiber etc.


Features:

Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine

Frond and back opening doors designs, conveniently for strapping

The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation

Equipped with independent emergency stop for safe operation

Equipped with Euro and U.S standard anti-rebound gate structure which makes sure the safety of operation

Special ram guides design makes the platen not slope because of uneven materials feedings during compression

Equipped with NOK seals that from Japan means longer lifespan of the seals

Equipped with A.M.C. oil pipe joints that from Japan ensures the machine far away from oil leakage problems

Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which replacing the common coupling connection so that extend the lifespan of the pump


Baling Press Machine, Soft Plastic Baler,Plastic Film Baler,Fiber Baler,Plastic Baler Machine

Technical Specifications:

Model

PNDB-300LE11070

PNDB-500LE12080

Pressure

30tons

50tons

Feed Opening Size (L*H)

1100*500mm

1200*500mm

Baling Chamber Height

1400mm

1500mm

Bale Size (L*W*H, H is adjustable)

1100*700*(300-900)mm

1200*800*(400-1000)mm

Bale Weight

60-150kgs

150-350kgs

Power

5.5KW

11kw

Machine Weight

1900kgs

2300kgs

Machine Overall Dimension

1500*1050*1900mm

1650*1200*3300mm


×
